main product photo
R 3 147,55 Inc VAT R 2 737,00 Exc VAT
Grouped product items
Product Name Qty
Double Blower Motor - SPAL 30001803
R 3 147,55 Inc VAT R 2 737,00 Exc VAT
Van Available 5-10 Days
Worldwide Delivery

Our shopping cart does its best to calculate the most accurate carriage cost for your order. The carriage is calculated based on the combined weight of the goods followed by the addition of product-related surcharges. Visit our Delivery Information Page for more information.

Worldwide Delivery
Save
Get Help Here Need some help? Click here to contact us

Double Blower Motor - SPAL 30001803 suitable for Case International - 82002761 82004366 90070010

Part No.

Product Details

76473

Product Details

Overall Length: 317mm.
Overall Height: 112mm.
Overall Width: 125mm.
Mounting Base Length: 317mm.
Mounting Base Width: 86mm.

12v.
Double Blower Wheel.
360 CFM.
14.1A Current Draw.
3 Speeds. Small Resistor Supplied.
Wire Harness With AMP Connector Supplied.

Maximum Airflow (At Zero Static Pressure): 360FM (610m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 005-A45-02 L301 RPA3VCB.
CB: Wire Harness With AMP Connector.
RPA: Small Resistor.
3V: 3 Speeds.
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.

Suitable For - Case International models , JX1060C, JX1070C, JX1070U, JX1075C, JX1080U, JX1090U, JX1100U, JX70U, JX80U, JX90U for OEM's 82002761, 82004366, 90070010

Fits Models

Product OEM
