Gear Reduction Starter Motor - 12V, 3.2Kw (Mahle) suitable for Fiat - 417213 4702248 4755109
Part No.
Product Details
93027
Product Details
Teeth: 9.
Tooth Pitch: 14.36mm.
Flange Ø: 110mm.
Mounting Angle: -55°.
Number Of Mounting Bores: 3.
Mounting Points Diameter: 146mm.
Bore Ø 1: 12.2mm.
Rotation Direction: Clockwise.
For Flywheel Depth: 30mm.
Suitable For - Fiat models , 65-46, 65-66, 65-88, 65-90, 65-93, 65-94, 70-56, 70-66, 70-76, 70-86, 70-88, 70-90, 72-93, 72-94, 80-66, 80-76, 80-88, 80-90, 82-93, 82-94, 85-90, 88-93, 88-94, L60, L65, L75, L85, L95 for OEM's 417213, 4702248, 4755109, 5801441814
Tooth Pitch: 14.36mm.
Flange Ø: 110mm.
Mounting Angle: -55°.
Number Of Mounting Bores: 3.
Mounting Points Diameter: 146mm.
Bore Ø 1: 12.2mm.
Rotation Direction: Clockwise.
For Flywheel Depth: 30mm.
Suitable For - Fiat models , 65-46, 65-66, 65-88, 65-90, 65-93, 65-94, 70-56, 70-66, 70-76, 70-86, 70-88, 70-90, 72-93, 72-94, 80-66, 80-76, 80-88, 80-90, 82-93, 82-94, 85-90, 88-93, 88-94, L60, L65, L75, L85, L95 for OEM's 417213, 4702248, 4755109, 5801441814
