R 26,45 Inc VAT
R 23,00
Exc VAT
Hydraulic Pump - 84530156 suitable for Fiat - 84530156 05129488 1909916
Part No.
Product Details
76496
Product Details
14.35CC Hydraulic gear pump.
Suitable For - Fiat models , 100-90, 1000, 110-90, 115-90, 1180, 1280, 130-90, 1380, 140-90, 1580, 160-90, 180-90, 1880, 466, 55-66, 566, 580, 60-66, 60-90, 60-93, 60-94, 65-66, 65-90, 65-93, 65-94, 666, 680, 70-66, 70-90, 72-93, 72-94, 766, 780, 80-66, 80-90, 82-93, 82-94, 85-90, 88-94, 880, 880-5, 90-90, 95-90, 980 for OEM's 84530156, 05129488, 1909916, 87716629, 1930226, 5113283, 5120850, 5129488, 5169770, 5179714, 9967927, 5179719, PRD22175, 356740M91, 8273957, 8280131, 5129483
Dimensions as follows -
Front inlet hole fixing hole size- M8
Front inlet hole fixing hole spacing - 40
Front inlet hole size - 20
Front outlet hole fixing hole size - M6
Front outlet hole fixing hole spacing - 30.2
Front outlet hole size - 13.5
Engine Displacement - 14.35 cc
Running Pressure - 210 bar
Speed at Max Working Pressure - 3000 RPM
Temperature Range -20°C to +110°C
Pump rotation - Anti-Clockwise
Pump type - Single Pump
Please Note - It is important to ensure that all fluids are clean when replacing a hydraulic pump, note that it is also recommended hydraulic filters are replaced at the same time to ensure no contamination to the pumps oil.
Suitable For - Fiat models , 100-90, 1000, 110-90, 115-90, 1180, 1280, 130-90, 1380, 140-90, 1580, 160-90, 180-90, 1880, 466, 55-66, 566, 580, 60-66, 60-90, 60-93, 60-94, 65-66, 65-90, 65-93, 65-94, 666, 680, 70-66, 70-90, 72-93, 72-94, 766, 780, 80-66, 80-90, 82-93, 82-94, 85-90, 88-94, 880, 880-5, 90-90, 95-90, 980 for OEM's 84530156, 05129488, 1909916, 87716629, 1930226, 5113283, 5120850, 5129488, 5169770, 5179714, 9967927, 5179719, PRD22175, 356740M91, 8273957, 8280131, 5129483
