Starter Motor Fordson Dexta suitable for Ford & Fordson - 957E11000 E1ADKN11001C Lucas 26071F

Kilowatts – 2.2KW

Number of Teeth – 11

Number of mounting holes – 3

Mounting hole diameter – 11mm

Total Length – 380mm

50097 is a direct replacement for the original Lucas 26071F starter motor. Commonly fitted to Fordson Dexta and Super Dexta tractors, mounted on the Right-hand side of the engine. Known as a pre engage starter fitted with an adjustable mounted contact switch and rubber boot. Manufactured using high grade copper for the internals this ensures the starter will last and be efficient. All external joints are sealed to keep out any moisture.

This starter is also a direct replacement for the original Fordson OEM 957E11000 or E1ADKN11001C

Starter motor cranking is activated by depressing a manual lever which contacts a switch sending power from the battery to the coil of a remote solenoid. Energising the solenoid coil causes the solenoid main contacts to close allowing flow of high current circuit from the battery to the starter motor. It’s not uncommon for a starter to fail after years of service especially with these starters as the rubber boot is prone to perishing allowing moisture in. Usual signs the starter motor is on its way out would be a single click from the starter or a series of rapid clicks when the ignition switch is turned to the start position, these symptoms can also point to a faulty solenoid rather than the motor itself.

If you require the rubber boot this is Agriline part number 5191, for replacement solenoids these can be ordered under Agriline part numbers 5171 and 5740

For original starter motors the contact switch is Agriline part number 5063

The Contact switch has 2 screw threaded terminals ready to connect the wiring up, its also important to check that the contact switch is set right so that the push lever makes contact with the switch and all the wires are making a good connection to both starter motor and tractor otherwise this could lead to further starting issues.
