Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" suitable for John Deere - AL116181 AL112951 AL200979
Part No.
Product Details
57026
Product Details
Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" - Male Thread Size M22 x 1.5
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: M22 x 1.5
Thread Length: 12.0mm
D1: 38.0mm / 1.5"
L1: 111.0mm / 4.37"
A/F: 32.0mm / 1.26"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Can be connected with residual pressure in the line (male side only)
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 300 bar (Flow in Litres Per Minute) - 4350 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1000 bar (Flow in Litres Per Minute) - 14500 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Suitable for Massey Ferguson.
Suitable For - John Deere models , 5620, 5720, 5820, 5425, 5425N, 6105M, 6110M, 6115M, 6120M, 6125M, 6130M, 6135M, 6140M, 6145M, 6155M, 6170M, 6175M, 6195M, 6105R, 6115R, 6125R, 6130R, 6140R, 6150R, 6170R, 6190R, 6100, 6200, 6300, 6400, 6500, 6506, 6600, 6800, 6900, 6010, 6110, 6210, 6310, 6410, 6510, 6610, 6810, 6910, 6215, 6415, 6020, 6120, 6220, 6310, 6320, 6420, 6520, 6620, 6820, 6920, 6130, 6330, 6430, 6530, 6630, 6830, 6930, 7515, 7130, 7230, 7330, 7430, 7530, 5080R, 5090R, 5100R, 5115R, 5125R, 5065M, 5075M, 5085M, 5090E, 5095M, 5100M, 5070M, 5080M, 5090M, 5105M, 5115M, 5100E, 5125M for OEM's AL116181, AL112951, AL200979
