Single Blower Motor - SPAL 30003542 suitable for John Deere - AL110881 AL173961 AL214942
Part No.
Product Details
80193
Product Details
For John Deere 2250, 2450, 2650, 2850, 3350, 3650 with Serial No. 646947 onwards.
For John Deere 2355, 2555, 2755, 2855N, 2955, 3155 with Serial No. 663475 onwards.
For John Deere 5000 E Series with Serial No. up to 340000.
For John Deere 7210, 7410, 7510 with Serial No. up to 055077.
For John Deere 710, 7810 with Serial No. up to 089999.
Overall Length: 175mm.
Overall Height: 152mm.
Overall Width: 182mm.
Mounting Base Length: 175mm.
Mounting Base Width: 143mm.
With PKSL Link Lead.
12v.
Single Blower Wheel.
338 CFM.
17A Current Draw.
Single Speed.
Standard Connector Wire Harness Included.
WP Packard Connector (Waterproof).
Includes heavy duty bearings and increased air flow from original OE John Deere Motor.
Maximum Airflow (At Zero Static Pressure): 338CFM (570m³/h).
Operating Voltage: 12v.
SPAL Type / Description: 023-A70-74D 12V BT Blower with PKSL Link Lead.
BT: Standard Connector.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
Suitable For - John Deere models , 2250, 2450, 2650, 2755, 2850, 3155, 3200, 3350, 3400, 3650, 5210, 5225, 5310, 5315, 5325, 5410, 5410N, 5415, 5425, 5425N, 5500, 5510, 5525, 5525N, 5620, 5625, 5720, 5820, 6020, 6100, 6110, 6120, 6130, 6200, 6210, 6215, 6220, 6230, 6300, 6310, 6310, 6320, 6320L, 6330, 6400, 6405, 6410, 6415, 6420, 6420S, 6430, 6500, 6506, 6510, 6520, 6520L, 6530, 6600, 6605, 6610, 6615, 6620, 6630, 6715, 6800, 6810, 6820, 6830, 6900, 6910, 6920, 6930, 7130, 7210, 7220, 7230, 7320, 7330, 7410, 7420, 7430, 7505, 7510, 7515, 7530, 7600, 7610, 7700, 7710, 7800, 7810, 5515, 5520, 5090E, 5220, 5320, 5100E for OEM's AL110881, AL173961, AL214942, AL75105, AL80700
