Starter Motor - 12V, 2.7Kw (Mahle) suitable for John Deere - AL70850 AL41247 AL62690

Teeth: 10
Tooth Pitch: 12.29mm
Flange Ø: 82.5mm
Mounting Angle: -45°
Number Of Mounting Bores: 2
Mounting Points Diameter: 105mm
Bore Ø 1: 13.5mm
Rotation Direction: Clockwise
For Flywheel Depth: 38mm

Suitable For - John Deere models , 1020, 1120, 2020, 2120, 3020, 3120, 820, 920, 1030, 1130, 1530, 1630, 1830, 2030, 2630, 3030, 3130, 830, 930, 3100, 3200, 3300, 3400, 3110, 3210, 3310, 3410, 1040, 1140, 1640, 1840, 2040, 2140, 2240, 2440, 2640, 2840, 2940, 3040, 3140, 3340, 3640, 4040, 4240, 840, 940, 4440, 4640, 4840, 1350, 1550, 1750, 1850, 1950, 2150, 2250, 2350, 2450, 2550, 2650, 2750, 2850, 2950, 3030, 3050, 3150, 3350, 3650, 4350, 5620, 2955, 2255, 2355, 2855, 2955, 3055, 3155, 3255, 6100, 6100SE, 6200, 6200SE, 6300, 6300SE, 6400, 6400SE, 6405, 6500, 6500L, 6010, 6010SE, 6110, 6110L, 6110SE, 6210, 6210L, 6210SE, 6310, 6310S, 6310SE, 6410, 6410L, 6410SE, 6510L, 6310, 7020, 8430, 8440, 8450 for OEM's AL70850, AL41247, AL62690, TY25952
