R 793,50 Inc VAT
R 690,00
Exc VAT
Related Items(5)
Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" suitable for Landini -
Part No.
Product Details
57026
Product Details
Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" - Male Thread Size M22 x 1.5
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: M22 x 1.5
Thread Length: 12.0mm
D1: 38.0mm / 1.5"
L1: 111.0mm / 4.37"
A/F: 32.0mm / 1.26"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Can be connected with residual pressure in the line (male side only)
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 300 bar (Flow in Litres Per Minute) - 4350 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1000 bar (Flow in Litres Per Minute) - 14500 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Suitable for Massey Ferguson.
Suitable For - Landini models , 5860, 6060, 6860, 6870, 6880, 7830, 7860, 7870, 7880, 8860, 8870, 8880
