4WD Hub Repair Kit - Later - Corteco Seal - 3426850M2 suitable for Massey Ferguson - 3429037M1 3428067M1 3429038M1
Part No.
Product Details
76125
Product Details
4WD Drive Hub Repair Kit.
Suitable for 300 Series Massey Ferguson Tractors.
Includes all the seals and bearings required to rebuild 4WD front hub assembly.
For seal kit only, order Agriline Part No. 76124.
Kit contains only Corteco brand seals; for kit containing Agriline Seals, order Agriline Part No. 76127.
**Note: Serial break applies**
From Serial / Engine No A43108.
From Serial / Engine No A34212.
Unsure on serial Info? Check outer diameter of outer hub seal; if diameter measures 195mm, this is the correct kit.
If outer diameter measures 190mm, you will require Agriline Hub Repair Kit (Agriline Part No. 76132).
Note on MF 383, 397, 393, 398, 399 this kit is only suitable for Serial No's B18009 - B189999
Kit includes:
Inner/ Outer Hub Bearing - 3426850M2 (2 of) (145 x 100 x 24mm).
King Pin - 3426523M2 (2 of).
King Pin Swivel Bearing - 3310930M91 (2 of) (64.3 x 30.16 x 24.43mm).
Drive Shaft Bush - 3426938M1 (44.9 x 40 x 40mm).
Outer Inner Hub Seal - 3429037M1 (195 x 170 x 18mm).
Inner, Inner Hub Seal - 3428067M1 (182 x 170 x 9mm).
Wear Ring - 3429038M1 (170 x 165 x 20mm).
Axle Seal - 3428064M1 (2 of) (60 x 40 x 18.5mm).
King Pin Seal - 3009744X1 (2 of) (3/32" x 1 1/8").
Kit is per side, universal LH & RH fit.
Suitable For - Massey Ferguson models , 340, 350, 355, 360, 362, 365, 375, 390, 390T, 396, 398, 399 for OEM's 3429037M1, 3428067M1, 3429038M1, 3428064M1, 3009744X1, 3426938M1, 3426523M2, 3310930M91, 3426938M1
