R 246,10 Inc VAT
R 214,00
Exc VAT
Quick Release Coupling - Female - Body Size 1/2" suitable for Massey Ferguson - 1610606M4 1680263M1
Part No.
Product Details
50235
Product Details
Quick Release Coupling - Female - Body Size 1/2" - Thread Size 3/4" - 16 UNF
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: 3/4" - 16 UNF
D1: 38.1mm / 1.5"
L1: 66mm / 2.6"
A/F: 27mm / 1.06"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Suitable For - Massey Ferguson models , 675, 690, 698, 698T, 699 for OEM's 1610606M4, 1680263M1
