Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" suitable for Massey Ferguson - 3796940M2 3796940M1 3796940M3
Part No.
Product Details
57026
Product Details
Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" - Male Thread Size M22 x 1.5
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: M22 x 1.5
Thread Length: 12.0mm
D1: 38.0mm / 1.5"
L1: 111.0mm / 4.37"
A/F: 32.0mm / 1.26"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Can be connected with residual pressure in the line (male side only)
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 300 bar (Flow in Litres Per Minute) - 4350 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1000 bar (Flow in Litres Per Minute) - 14500 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Suitable for Massey Ferguson.
Suitable For - Massey Ferguson models , 265, 275, 283, 290, 298, 340, 342, 350, 352, 355, 360, 362, 365, 372, 374, 375, 382, 383, 384, 387, 390, 390T, 393, 396, 397, 398, 399, 3090, 3120, 3630, 3650, 3660, 3680, 4215, 4220, 4225, 4235, 4240, 4245, 4255, 4260, 4265, 4270, 4315, 4320, 4325, 4355, 4360, 4365, 4370, 5425, 5435, 5445, 5455, 5460, 5465, 670, 675, 690, 698, 698T, 699, 6235, 6245, 6255, 6260, 6265, 6270, 6280, 6290, 6445, 6455, 6460, 6470, 7465, 7475, 7480, 7485, 7490, 7495, 415, 435, 440, 475, 425, 460, 465 for OEM's 3796940M2, 3796940M1, 3796940M3, 3384873M4, 3384873M5, 3384873M7, 3384873M8, 3384874M4, 3772942M1, 3794298M1, 3794298M2, 3905722M91
