Quick Release Coupling - Female - Body Size 1/2"
Part No.
Product Details
57013
Product Details
Quick Release Coupling - Female - Body Size 1/2" - Male Thread Size M22 x 1.5 - Thread Length 12mm
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: Male M22 x 1.5
Thread Length: 12mm
D1: 38.1mm / 1.5"
L1: 89.0mm / 3.50"
A/F: 27.0mm / 1.06"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
