R 132,25 Inc VAT
R 115,00
Exc VAT
Related Items(1)
Quick Release Coupling - Male - Body Size 3/4"
Part No.
Product Details
57006
Product Details
Quick Release Coupling - Male - Body Size 3/4" - Thread Size 3/4" BSPP
This series of ISO A couplings are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to agricultural and industrial applications.
Body Size: 3/4”
Thread: 3/4" BSPP
D2: 29.1mm / 1.14"
L2: 57mm / 2.24"
A/F: 35mm / 1.38"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Poppet valves have balanced springs
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 350 bar (Flow in Litres Per Minute) - 5075 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1800 bar (Flow in Litres Per Minute) - 26100 PSI (Flow in Gallons Per Minute)
• Rated Flow - 23 bar (Flow in Litres Per Minute) – 6.1 PSI (Flow in Gallons Per Minute)
